Installation Pre Condition

Pre-Conditions for a Perfect Stretch Ceiling Installation

Ensure these pre-conditions are met before installing a stretch ceiling for a smooth, durable finish.

Room Completion: All major construction, painting, and plastering must be finished.
Dry & Dust-Free Environment: The space must be clean, dust-free, and moisture-controlled.
Existing Functional Space: Cover furniture and remove small items for a clean, damage-free process.

All wiring, fixtures, and mounting points must be in place before installation.
Place Outside the Stretch Ceiling

Avoid placing SMPS/drivers inside the stretch ceiling to prevent the need for fabric removal during servicing. Best Practice – Install drivers and power supplies outside the ceiling for easy access and future servicing.
In Case of Placement Inside the Ceiling

If it is absolutely necessary to place the drivers inside the stretch ceiling, ensure they are housed within a trap door or a removable access panel. This allows easy servicing without disturbing or removing the stretch fabric.
Distance from Drivers to Lighting Fixtures

The ideal distance between the driver and light fixture should be within 5 meters to avoid voltage drop and ensure consistent lighting performance. If the drivers need to be placed beyond 5 meters, ensure the proper wire thickness is used to compensate for the distance and avoid lighting loss. Please refer to the picture below where the illustration is based on 160W SMPS

Wooden Box

Depth – 150mm (to accommodate lighting and fixtures)

Side Drops – 19mm plywood for stability

Back Sheet – 12mm or 19mm plywood (depending on load / price requirements)

Surface Finish for Best Light Reflection

White Laminated Finish (Preferred) – Ensures uniform light diffusion

White Painted Finish (Alternative) – Only if the coating is uniform and consistent

Avoid uneven paint – Inconsistent coating causes black spots due to irregular reflection
